Specifications
- Additional Feature
- PA, UL 94V-0
- Özellikler
- Mating Flange
- Connector Type
- Socket
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Polyamide (PA), Nylon
- Insulation Height
- 0.307 7.80mm
- Wire Gauge Or Range Mm
- 0.2-1.5mm2
- Montaj Tipi
- Free Hanging (In-Line)
- Fastening Method
- SPRING LOADED
- Wire Gauge Or Range Awg
- 16-24 AWG
- Fabrika Tedarik Süresi
- 4 Weeks
- Kurşunsuz
- Lead Free
- Kurşunsuz Kodu
- yes
- Wire Gauge Max
- 24 AWG
- Number Of Decks
- 1
- Sıra Sayısı
- 1
- Wire Strip Length
- 10mm
- Terminal
- Screwless
- Renk
- Green
- Seri
- COMBICON FMC
- Onay Kuruluşu
- CB, VDE, cULus
- Weight
- 89.000011g
- Wire Gauge Min
- 16 AWG
- Pitch
- 0.138 3.50mm
- Akım
- 8A
- Parça Durumu
- Active
- ECCN Kodu
- EAR99
- Nominal Gerilim
- 160V
- Material Flammability Rating
- UL94 V-0
- Genişlik
- 22.9mm
- Yayın Yılı
- 2003
- HTS Kodu
- 8536.69.40.40
- Voltageiec
- 320V
- Number Of Levels
- 1
- Flammability Rating
- UL94 V-0
- Ambalaj
- Bulk
- RoHS Durumu
- RoHS Compliant
- Number Of Ways
- 2
- Plug Wire Entry
- 180°
- Gerilim
- 150V
