Volume pricing
- 1+ pcs$5.14
- 10+ pcs$4.85
- 100+ pcs$4.58
- 500+ pcs$4.32
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Uzunluk
- 25.7mm
- Sıra Sayısı
- 2
- Yükseklik
- 22.1mm
- Özellikler
- Mating Flange, Retention Latches (Non-Wire Side)
- Number Of Levels
- 1 (Mate), 2 (Input)
- Renk
- Green
- Nominal Gerilim
- 320V
- Plug Wire Entry
- 180°
- Voltageiec
- 630V
- Positions Per Level
- 9 (Mate), 18 (Input)
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Gauge Or Range Awg
- 12-26 AWG
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Fastening Method
- SPRING LOADED
- Montaj
- Free Hanging
- Akım
- 10A
- Montaj Tipi
- Free Hanging (In-Line)
- Wire Gauge Max
- 26 AWG
- Material
- Polyamide, Tin
- Material Flammability Rating
- UL94 V-0
- Depth
- 25.7mm
- Safety Approval
- UL
- Weight
- 143.000013g
- Radyasyon Dayanımı
- No
- Parça Durumu
- Active
- Tip
- Plug, Female Sockets
- Orientation
- Right Angle
- Housing Material
- Polyamide (PA), Nylon
- Number Of Ways
- 9
- Wire Gauge Min
- 12 AWG
- Ambalaj
- Bulk
- Max Current Rating
- 12A
- Gender
- Female
- Contact Mating Finish
- Tin
- Number Of Decks
- 1
- Wire Strip Length
- 10mm
- Pozisyon Sayısı
- 9
- Seri
- COMBICON TFKC
- Akım Değeri
- 12A
- RoHS Durumu
- RoHS Compliant
