Volume pricing
- 1+ pcs$2.74
- 10+ pcs$2.59
- 100+ pcs$2.44
- 500+ pcs$2.30
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- RoHS Compliant
- Depth
- 22.9mm
- ECCN Kodu
- EAR99
- Seri
- COMBICON FMC
- Pitch
- 0.138 3.50mm
- Connector Type
- Socket
- Wire Gauge Or Range Mm
- 0.2-1.5mm2
- Number Of Positions Per Level
- 10
- Renk
- Green
- Sıra Sayısı
- 1
- Orientation
- Straight
- Plug Wire Entry
- 180°
- Wire Gauge Or Range Awg
- 16-24 AWG
- Contact Mating Finish
- Tin
- Fastening Method
- SPRING LOADED
- Akım
- 8A
- Fabrika Tedarik Süresi
- 7 Weeks
- Uzunluk
- 35.7mm
- Wire Gauge Min
- 24 AWG
- Yükseklik
- 22.9mm
- Safety Approval
- UL; IEC
- Nominal Gerilim
- 160V
- Material Flammability Rating
- UL94 V-0
- Kurşunsuz
- Lead Free
- Flammability Rating
- UL94 V-0
- Max Current Rating
- 8A
- Akım Değeri
- 8A
- Number Of Levels
- 1
- Genişlik
- 35.7mm
- Terminal
- Screwless
- Terminal Stili
- Screwless - Push-In Spring
- Gender
- Female
- Ambalaj
- Bulk
- Montaj Tipi
- Free Hanging (In-Line)
- Wire Gauge Max
- 16 AWG
- HTS Kodu
- 8536.69.40.40
- Montaj
- Free Hanging
- Insulation Height
- 0.307 7.80mm
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2003
