Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Safety Approval
- UL
- Nominal Gerilim
- 160V
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Min
- 16 AWG
- Yükseklik
- 22.9mm
- Max Current Rating
- 8A
- Akım Değeri
- 8A
- Kurşunsuz
- Lead Free
- Flammability Rating
- UL94 V-0
- Contact Mating Finish
- Tin
- Fastening Method
- SPRING LOADED
- Akım
- 8A
- Fabrika Tedarik Süresi
- 7 Weeks
- Uzunluk
- 7.8mm
- Orientation
- Straight
- Plug Wire Entry
- 180°
- Wire Gauge Or Range Awg
- 16-24 AWG
- Wire Gauge Or Range Mm
- 0.2-1.5mm2
- Renk
- Green
- Sıra Sayısı
- 1
- RoHS Durumu
- RoHS Compliant
- ECCN Kodu
- EAR99
- Seri
- COMBICON FMC
- Connector Type
- Socket
- Pitch
- 0.138 3.50mm
- Contact Materials
- Copper
- Voltageiec
- 320V
- Number Of Contacts
- 8
- Wire Strip Length
- 10mm
- Tip
- Plug, Female Sockets
- Number Of Decks
- 1
- Number Of Ways
- 8
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Polyamide (PA), Nylon
- Additional Feature
- PA, 94V-0
- Parça Durumu
- Active
- Weight
- 4.329993g
- Wire Gauge Max
- 24 AWG
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2003
