Volume pricing
- 1+ pcs$2.61
- 10+ pcs$2.46
- 100+ pcs$2.32
- 500+ pcs$2.19
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Akım Değeri
- 8A
- Özellikler
- Latch Lock
- Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 160V
- Material Flammability Rating
- UL94 V-0
- Safety Approval
- UL
- Wire Gauge Min
- 16 AWG
- Yükseklik
- 7.8mm
- Uzunluk
- 22.9mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Fastening Method
- SPRING LOADED
- Akım
- 8A
- Contact Plating
- Tin
- REACH Uyumluluk Kodu
- unknown
- Wire Gauge Or Range Awg
- 16-24 AWG
- Plug Wire Entry
- 180°
- Wire Gauge Or Range Mm
- 0.2-1.5mm2
- Sıra Sayısı
- 1
- Number Of Positions Per Level
- 8
- Renk
- Green
- Connector Type
- Socket
- Pitch
- 0.138 3.50mm
- RoHS Durumu
- RoHS Compliant
- ECCN Kodu
- EAR99
- Depth
- 7.8mm
- Seri
- COMBICON FMC
- Voltageiec
- 320V
- Wire Strip Length
- 10mm
- Material
- Polyamide, Tin
- Parça Durumu
- Active
- Weight
- 4.780013g
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Polyamide (PA), Nylon
- Additional Feature
- PA, UL 94V-0
- Tip
- Plug, Female Sockets
- Number Of Decks
- 1
- Number Of Ways
- 8
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2003
- Gerilim
- 150V
