Volume pricing
- 1+ pcs$2.22
- 10+ pcs$2.10
- 100+ pcs$1.98
- 500+ pcs$1.87
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Safety Approval
- UL
- Number Of Positions Per Level
- 4
- Parça Durumu
- Active
- Housing Material
- Polyamide (PA), Nylon
- Pitch
- 0.200 5.08mm
- Tip
- Plug, Female Sockets
- Wire Cross Section
- 2.5 mm2
- Weight
- 7.939993g
- Wire Gauge Max
- 12 AWG
- Terminal Stili
- Screwless - Push-In Spring
- Material
- Polyamide, Tin
- Number Of Ways
- 4
- Nominal Gerilim
- 250V
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2011
- Flammability Rating
- UL94 V-0
- Akım
- 16A
- Ambalaj
- Bulk
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Material Flammability Rating
- UL94 V-0
- Number Of Decks
- 1
- Wire Gauge Min
- 24 AWG
- Voltageiec
- 630V
- Terminal
- Screwless
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 12A
- Wire Strip Length
- 10mm
- Montaj Tipi
- Free Hanging (In-Line)
- Fabrika Tedarik Süresi
- 4 Weeks
- ECCN Kodu
- EAR99
- Montaj
- Free Hanging
- Gerilim
- 300V
- Contact Mating Finish
- Tin
- Özellikler
- Mating Flange, Retention Latches (Non-Wire Side)
- Seri
- COMBICON FKC
- Sıra Sayısı
- 1
- Number Of Levels
- 1
- Plug Wire Entry
- 180°
- Wire Gauge Or Range Awg
- 12-26 AWG
- Renk
- Green
