Volume pricing
- 1+ pcs$1.04
- 10+ pcs$0.98
- 100+ pcs$0.93
- 500+ pcs$0.87
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material
- Polyamide
- Connector Type
- Socket
- Nominal Gerilim
- 250V
- Number Of Positions Per Level
- 2
- Tip
- Plug, Female Sockets
- Pitch
- 0.200 5.08mm
- Ambalaj
- Bulk
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Contact Plating
- Tin
- ECCN Kodu
- EAR99
- Montaj
- Free Hanging, Plug-In
- Material Flammability Rating
- UL94 V-0
- Voltageiec
- 630V
- Uzunluk
- 10.78mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Retention Latches (Non-Wire Side)
- Seri
- COMBICON FKC
- Sıra Sayısı
- 1
- Insulation Height
- 0.591 15.00mm
- Onay Kuruluşu
- CB, VDE, cULus
- Orientation
- Straight
- Terminal Stili
- Screwless - Push-In Spring
- Wire Gauge Max
- 12 AWG
- Number Of Ways
- 2
- Safety Approval
- UL
- Depth
- 15mm
- Parça Durumu
- Active
- Housing Material
- Polyamide (PA), Nylon
- Additional Feature
- PA, UL 94V-0
- Flammability Rating
- UL94 V-0
- Akım
- 16A
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2013
- Genişlik
- 25.6mm
- Akım Değeri
- 16A
- Wire Strip Length
- 10mm
- Montaj Tipi
- Free Hanging (In-Line)
- Fabrika Tedarik Süresi
- 4 Weeks
- Number Of Decks
- 1
- Wire Gauge Min
- 24 AWG
