Volume pricing
- 1+ pcs$4.99
- 10+ pcs$4.70
- 100+ pcs$4.44
- 500+ pcs$4.19
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Plating
- Tin
- Gerilim
- 300V
- Plug Wire Entry
- 180°
- Terminal Stili
- Screwless - Push-In Spring
- Number Of Decks
- 1
- Montaj Tipi
- Free Hanging (In-Line)
- Max Current Rating
- 8A
- Wire Gauge Max
- 16 AWG
- Material Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 160V
- HTS Kodu
- 8536.69.40.40
- Terminal
- Screwless
- Housing Material
- Polyamide (PA), Nylon
- RoHS Durumu
- RoHS Compliant
- Voltageiec
- 320V
- Number Of Contacts
- 12
- Kurşunsuz Kodu
- yes
- Safety Approval
- UL
- Orientation
- Straight
- Montaj
- Cable, Free Hanging
- Yükseklik
- 20.8mm
- Akım Değeri
- 8A
- Max Supply Voltage
- 160V
- Genişlik
- 20.8mm
- Akım
- 8A
- Additional Feature
- PA, UL 94V-0
- Seri
- COMBICON FK-MCP
- Number Of Levels
- 1
- Fastening Method
- SPRING LOADED
- Weight
- 10.23001g
- Pitch
- 0.138 3.50mm
- ECCN Kodu
- EAR99
- Uzunluk
- 42.9mm
- Ambalaj
- Bulk
- Wire Gauge Min
- 26 AWG
- Insulation Height
- 0.488 12.40mm
- Material
- Polyamide
- Number Of Ways
- 12
- Tip
- Plug, Female Sockets
- Renk
- Green
