Volume pricing
- 1+ pcs$1.75
- 10+ pcs$1.65
- 100+ pcs$1.55
- 500+ pcs$1.47
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Weight
- 10.760005g
- Housing Material
- Polyamide (PA), Nylon
- Parça Durumu
- Active
- Wire Gauge Or Range Awg
- 12-26 AWG
- Sıra Sayısı
- 1
- Number Of Decks
- 1
- Wire Strip Length
- 10mm
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 12A
- Fastening Method
- SPRING LOADED
- ECCN Kodu
- EAR99
- Insulation Height
- 0.591 15.00mm
- Plug Wire Entry
- 180°
- Gerilim
- 300V
- Wire Gauge Min
- 24 AWG
- Özellikler
- Mating Flange, Retention Latches (Non-Wire Side)
- Gender
- Female
- Safety Approval
- UL
- Number Of Positions Per Level
- 5
- Montaj Tipi
- Free Hanging (In-Line)
- Wire Gauge Max
- 12 AWG
- Nominal Gerilim
- 400V
- Number Of Levels
- 1
- Montaj
- Free Hanging
- Material
- Polyamide, Tin
- Pitch
- 0.300 7.62mm
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Terminal Stili
- Screwless - Push-In Spring
- RoHS Durumu
- RoHS Compliant
- Seri
- COMBICON GFKC
- Contact Mating Finish
- Tin
- Number Of Ways
- 5
- Currentiec
- 12A
- Tip
- Plug, Female Sockets
- Yayın Yılı
- 2011
- Akım
- 10A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Additional Feature
- PA, UL 94V-0
- Material Flammability Rating
- UL94 V-0
- Terminal
- Screwless
