Volume pricing
- 1+ pcs$1.15
- 10+ pcs$1.09
- 100+ pcs$1.03
- 500+ pcs$0.97
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Housing Material
- Polyamide (PA), Nylon
- Wire Gauge Or Range Awg
- 12-26 AWG
- Parça Durumu
- Active
- Uzunluk
- 15mm
- Connector Type
- Socket
- Montaj Tipi
- Free Hanging (In-Line)
- Wire Gauge Max
- 26 AWG
- Safety Approval
- UL
- Plug Wire Entry
- 180°
- Wire Gauge Min
- 12 AWG
- Gerilim
- 300V
- ECCN Kodu
- EAR99
- Number Of Levels
- 1
- Terminal Stili
- Screwless - Push-In Spring
- Contact Plating
- Tin
- Pitch
- 0.300 7.62mm
- Akım
- 10A
- Currentiec
- 12A
- Number Of Ways
- 3
- Terminal
- Screwless
- Material Flammability Rating
- UL94 V-0
- Additional Feature
- PA, UL 94V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Flammability Rating
- UL94 V-0
- Weight
- 5.859988g
- Number Of Decks
- 1
- Wire Strip Length
- 10mm
- Kurşunsuz Kodu
- yes
- Sıra Sayısı
- 1
- Genişlik
- 25.6mm
- Number Of Positions Per Level
- 3
- Gender
- Female
- Özellikler
- Retention Latches (Non-Wire Side)
- Insulation Height
- 0.591 15.00mm
- Akım Değeri
- 12A
- Fastening Method
- SPRING LOADED
- Nominal Gerilim
- 400V
- Yükseklik
- 20.94mm
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
