Volume pricing
- 1+ pcs$1.10
- 10+ pcs$1.04
- 100+ pcs$0.98
- 500+ pcs$0.92
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material
- Polyamide
- Parça Durumu
- Active
- Mating Orientation
- Horizontal with Board
- Stripping Length
- 5mm
- Terminal
- Solder
- Akım
- 18A
- Number Of Contacts
- 8
- Insulation Materials
- Nylon
- Onay Kuruluşu
- CB, UL, VDE
- Genişlik
- 9mm
- ECCN Kodu
- EAR99
- Uzunluk
- 40mm
- Number Of Decks
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Max Current Rating
- 17.5A
- Ambalaj
- Bulk
- Screw Thread
- M2.6
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Max
- 26 AWG
- Orientation
- Straight
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Kurşunsuz
- Lead Free
- Max Supply Voltage
- 250V
- Housing Material
- Polyamide (PA), Nylon
- Özellikler
- Interlocking (Side)
- Wire Gauge Min
- 12 AWG
- Depth
- 9mm
- Akım Değeri
- 17.5A
- Montaj
- Through Hole
- Seri
- COMBICON PT
- Additional Feature
- PA, 94V-0
- Radyasyon Dayanımı
- No
- Contact Materials
- Copper
- Number Of Levels
- 1
- Contact Plating
- Tin
- Weight
- 7.628006g
- Gerilim
- 300V
- Yayın Yılı
- 2011
- Wire Termination
- Screw
