Volume pricing
- 1+ pcs$1.32
- 10+ pcs$1.25
- 100+ pcs$1.18
- 500+ pcs$1.11
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Contacts
- 10
- Akım
- 15A
- Wirecable Gauge
- 12 AWG
- Plug Wire Entry
- 90°
- Connector Type
- Screw
- Stripping Length
- 5mm
- Parça Durumu
- Active
- ECCN Kodu
- EAR99
- Genişlik
- 45mm
- Onay Kuruluşu
- UL, cULus
- Insulation Materials
- Nylon
- Ambalaj
- Bulk
- Max Current Rating
- 12A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Number Of Decks
- 1
- Uzunluk
- 14.9mm
- Wire Gauge Or Range Awg
- 12-26 AWG
- Contact Mating Finish
- Tin
- HTS Kodu
- 8536.69.40.40
- Wire Gauge Min
- 26 AWG
- Max Supply Voltage
- 250V
- Housing Material
- Polyamide (PA), Nylon
- Kurşunsuz
- Lead Free
- Orientation
- Right Angle/Straight
- Voltage Rated Dc
- 320V
- Wire Gauge Max
- 14 AWG
- RoHS Durumu
- RoHS Compliant
- Screw Size
- M2.6
- Additional Feature
- PA, 94V-0
- Seri
- COMBICON PT
- Montaj
- Cable, Free Hanging
- Akım Değeri
- 12A
- Tip
- Plug for Unshrouded Header
- Depth
- 15mm
- Terminal Stili
- Screw - Rising Cage Clamp
- Yayın Yılı
- 2003
- Gerilim
- 300V
- Weight
- 11.460011g
- Number Of Levels
- 1
