Specifications
- Renk
- Green
- Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 250V
- Fabrika Tedarik Süresi
- 18 Weeks
- Number Of Ways
- 4
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Safety Approval
- UL
- Sıra Sayısı
- 1
- Montaj Tipi
- Free Hanging (In-Line)
- Insulation Height
- 0.449 11.40mm
- Voltageiec
- 630V
- Pitch
- 0.197 5.00mm
- Yükseklik
- 11.3mm
- Material Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2003
- Min. Çalışma Sıcaklığı
- -40°C
- Gerilim
- 300V
- Weight
- 4.580007g
- Radyasyon Dayanımı
- No
- Contact Materials
- Copper
- Number Of Levels
- 1
- Terminal Stili
- Screw - Rising Cage Clamp
- Tip
- Plug for Unshrouded Header
- Depth
- 15mm
- Akım Değeri
- 12A
- Montaj
- Free Hanging, Through Hole
- Seri
- COMBICON PT
- Test Voltage
- 4kV
- Wire Gauge Max
- 26 AWG
- RoHS Durumu
- RoHS Compliant
- Screw Size
- M2.6
- Wire Gauge Min
- 12 AWG
- Kurşunsuz
- Lead Free
- Max Supply Voltage
- 250V
- Housing Material
- Polyamide (PA), Nylon
- Orientation
- Right Angle/Straight
- Wire Gauge Or Range Awg
- 12-26 AWG
- Contact Mating Finish
- Tin
- Max Current Rating
- 12A
- Ambalaj
- Bulk
