Volume pricing
- 1+ pcs$1.33
- 10+ pcs$1.26
- 100+ pcs$1.18
- 500+ pcs$1.12
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Seri
- COMBICON MKDSP
- Yayın Yılı
- 2011
- Mating Orientation
- Horizontal with Board
- Terminal
- Screw
- Screw Thread
- M4
- Fabrika Tedarik Süresi
- 4 Weeks
- Number Of Ways
- 2
- Contact Materials
- Tin
- Wire Gauge Max
- 20 AWG
- Wire Gauge Min
- 6 AWG
- Montaj
- Through Hole
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Safety Approval
- UL
- Yükseklik
- 31mm
- Akım
- 60A
- Genişlik
- 35.8mm
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 76A
- Number Of Levels
- 1
- Renk
- Green
- Uzunluk
- 20.32mm
- RoHS Durumu
- RoHS Compliant
- Flammability Rating
- UL94 V-0
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Housing Material
- Polyamide (PA), Nylon
- Pitch
- 0.400 10.16mm
- Pozisyon Sayısı
- 2
- Wire Gauge
- 6-20 AWG
- Insulation Materials
- Nylon
- Wire Termination
- Screw - Rising Cage Clamp
- Nominal Gerilim
- 1kV
- Number Of Decks
- 1
- Additional Feature
- PA, 94V-0
- Montaj Tipi
- Through Hole
- ECCN Kodu
- EAR99
- Weight
- 17.109986g
- Özellikler
- Interlocking (Side)
- Sıra Sayısı
- 1
- HTS Kodu
- 8536.69.40.40
