Volume pricing
- 1+ pcs$2.31
- 10+ pcs$2.18
- 100+ pcs$2.06
- 500+ pcs$1.94
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- REACH Uyumluluk Kodu
- not_compliant
- Number Of Contacts
- 4
- RoHS Durumu
- RoHS Compliant
- Number Of Levels
- 1
- Material
- Polyamide, Tin
- Terminal Stili
- Screw - Rising Cage Clamp
- Orientation
- Right Angle
- Wire Gauge Min
- 24 AWG
- Seri
- COMBICON MSTBT
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Gauge Or Range Awg
- 12-30 AWG
- Tip
- Plug, Female Sockets
- Uzunluk
- 15mm
- Gender
- Female
- Material Flammability Rating
- UL94 V-0
- Voltageiec
- 630V
- Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 250V
- Genişlik
- 20mm
- Gerilim
- 300V
- Wire Cross Section
- 2.5 mm2
- Yükseklik
- 18.2mm
- Montaj
- Cable, Free Hanging
- ECCN Kodu
- EAR99
- Özellikler
- Retention Latches (Non-Wire Side)
- Housing Material
- Polyamide (PA), Nylon
- Montaj Tipi
- Free Hanging (In-Line)
- Kurşunsuz Kodu
- yes
- Weight
- 6.810009g
- Terminal
- Screw
- Connector Type
- Screw, Socket
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Safety Approval
- UL
- Plug Wire Entry
- 180°
- Akım Değeri
- 16A
- Number Of Ways
- 4
- Screw Size
- M3
- Wire Strip Length
- 7mm
- Yayın Yılı
- 2001
- Insulation Height
- 0.591 15.00mm
