Volume pricing
- 1+ pcs$1.74
- 10+ pcs$1.64
- 100+ pcs$1.55
- 500+ pcs$1.46
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltageiec
- 630V
- Gender
- Female
- Material Flammability Rating
- UL94 V-0
- Flammability Rating
- UL94 V-0
- Fabrika Tedarik Süresi
- 4 Weeks
- Uzunluk
- 6.6mm
- Wire Gauge Or Range Awg
- 12-30 AWG
- Tip
- Plug, Female Sockets
- Yükseklik
- 15mm
- Wire Cross Section
- 2.5 mm2
- Genişlik
- 18.2mm
- Nominal Gerilim
- 250V
- Gerilim
- 300V
- Montaj
- Cable, Free Hanging
- Housing Material
- Polyamide (PA), Nylon
- Kurşunsuz Kodu
- yes
- Montaj Tipi
- Free Hanging (In-Line)
- Depth
- 6.2mm
- Özellikler
- Retention Latches (Non-Wire Side)
- ECCN Kodu
- EAR99
- REACH Uyumluluk Kodu
- unknown
- Number Of Levels
- 1
- Material
- Polyamide, Tin
- Number Of Contacts
- 3
- RoHS Durumu
- RoHS Compliant
- Orientation
- Right Angle
- Terminal Stili
- Screw - Rising Cage Clamp
- Seri
- COMBICON MSTBT
- Wire Gauge Min
- 12 AWG
- Wire Gauge Max
- 30 AWG
- Max Current Rating
- 16A
- Additional Feature
- PA, UL 94V0
- Sıra Sayısı
- 1
- Pitch
- 0.197 5.00mm
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Akım
- 16A
- Number Of Decks
- 1
- Contact Plating
- Tin
- Terminal
- Screw
- Weight
- 5.080008g
