Volume pricing
- 1+ pcs$1.94
- 10+ pcs$1.83
- 100+ pcs$1.73
- 500+ pcs$1.63
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Levels
- 1
- ECCN Kodu
- EAR99
- Renk
- Green
- Insulation Height
- 1.024 26.01mm
- Tip
- Plug, Female Sockets
- Pitch
- 0.197 5.00mm
- HTS Kodu
- 8536.69.40.40
- Parça Durumu
- Active
- Wire Gauge Max
- 12 AWG
- Number Of Decks
- 1
- Voltageiec
- 630V
- Montaj Tipi
- Free Hanging (In-Line)
- Number Of Positions Per Level
- 2
- Depth
- 26mm
- Seri
- COMBICON MVSTBR
- Material
- Polyamide
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Orientation
- Straight
- Yükseklik
- 26mm
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Nominal Gerilim
- 250V
- Montaj
- Free Hanging, Plug-In
- Uzunluk
- 11mm
- Sıra Sayısı
- 1
- Number Of Ways
- 2
- Gender
- Female
- Akım
- 16A
- Screw Size
- M3
- Yayın Yılı
- 2001
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Awg
- 12-30 AWG
- Gerilim
- 300V
- Housing Material
- Polyamide (PA), Nylon
- Material Flammability Rating
- UL94 V-0
- Safety Approval
- UL
- Wire Gauge Min
- 24 AWG
- Terminal Stili
- Screw - Rising Cage Clamp
- Plug Wire Entry
- 90°
- Kurşunsuz Kodu
- yes
- Genişlik
- 12.6mm
