Volume pricing
- 1+ pcs$1.78
- 10+ pcs$1.68
- 100+ pcs$1.58
- 500+ pcs$1.49
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Genişlik
- 12.6mm
- Weight
- 8.380006g
- Özellikler
- Retention Latches (Wire Side)
- Gerilim
- 300V
- Terminal Stili
- Screw - Rising Cage Clamp
- Wire Gauge Min
- 12 AWG
- Safety Approval
- UL
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Polyamide (PA), Nylon
- Kurşunsuz Kodu
- yes
- Plug Wire Entry
- 90°
- Wire Cross Section
- 2.5 mm2
- Ambalaj
- Bulk
- Connector Type
- Screw
- Contact Mating Finish
- Tin
- RoHS Durumu
- RoHS Compliant
- Akım Değeri
- 16A
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Strip Length
- 7mm
- Onay Kuruluşu
- CB, VDE, cULus
- Tip
- Plug, Female Sockets
- Pitch
- 0.200 5.08mm
- Voltageiec
- 630V
- Parça Durumu
- Active
- Wire Gauge Max
- 30 AWG
- Number Of Decks
- 1
- Number Of Levels
- 1
- ECCN Kodu
- EAR99
- Insulation Height
- 1.024 26.01mm
- Renk
- Green
- Uzunluk
- 4.98mm
- Montaj
- Free Hanging, Plug-In
- Sıra Sayısı
- 1
- Screw Size
- M3
- Akım
- 16A
- Gender
- Female
- Number Of Ways
- 4
- Wire Gauge Or Range Awg
- 12-30 AWG
- Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2001
