Volume pricing
- 1+ pcs$1.85
- 10+ pcs$1.75
- 100+ pcs$1.65
- 500+ pcs$1.55
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Renk
- Green
- Contact Plating
- Tin
- Kurşunsuz Kodu
- yes
- Insulation Height
- 0.591 15.00mm
- Plug Wire Entry
- 180°
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Polyamide (PA), Nylon
- Terminal Stili
- Screw - Rising Cage Clamp
- ECCN Kodu
- EAR99
- Wire Gauge Min
- 24 AWG
- Safety Approval
- UL
- Number Of Levels
- 1
- Terminal
- Screw
- Gerilim
- 300V
- Voltageiec
- 630V
- Özellikler
- Mating Flange
- Number Of Decks
- 1
- Wire Gauge Max
- 12 AWG
- Parça Durumu
- Active
- Pitch
- 0.197 5.00mm
- Weight
- 7.650005g
- Genişlik
- 29.4mm
- Tip
- Plug, Female Sockets
- Wire Strip Length
- 7mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Akım Değeri
- 16A
- Nominal Gerilim
- 250V
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Yükseklik
- 18.2mm
- Montaj Tipi
- Free Hanging (In-Line)
- Seri
- COMBICON MSTB
- Material
- Polyamide, Tin
- Number Of Positions Per Level
- 4
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Connector Type
- Screw, Socket
- Wire Gauge Or Range Awg
- 12-30 AWG
- Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2001
- Gender
- Female
