Volume pricing
- 1+ pcs$1.39
- 10+ pcs$1.31
- 100+ pcs$1.23
- 500+ pcs$1.16
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Safety Approval
- UL
- Wire Gauge Min
- 24 AWG
- Terminal Stili
- Screw - Rising Cage Clamp
- Housing Material
- Polyamide (PA), Nylon
- Material Flammability Rating
- UL94 V-0
- Plug Wire Entry
- 180°
- Kurşunsuz Kodu
- yes
- Gerilim
- 300V
- Özellikler
- Mating Flange
- Genişlik
- 24.4mm
- Weight
- 6.000006g
- Additional Feature
- PA, UL 94V0
- RoHS Durumu
- RoHS Compliant
- Akım Değeri
- 16A
- Fabrika Tedarik Süresi
- 7 Weeks
- Wire Strip Length
- 7mm
- Ambalaj
- Bulk
- Connector Type
- Screw, Socket
- Wire Cross Section
- 2.5 mm2
- ECCN Kodu
- EAR99
- Insulation Height
- 0.591 15.00mm
- Contact Plating
- Tin
- Renk
- Green
- Number Of Levels
- 1
- Terminal
- Screw
- Pitch
- 0.197 5.00mm
- Parça Durumu
- Active
- Wire Gauge Max
- 12 AWG
- Number Of Decks
- 1
- Voltageiec
- 630V
- Tip
- Plug, Female Sockets
- Nominal Gerilim
- 250V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Free Hanging (In-Line)
- Number Of Positions Per Level
- 3
- Material
- Polyamide, Tin
- Seri
- COMBICON MSTB
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Yükseklik
- 18.2mm
- Akım
- 16A
