Volume pricing
- 1+ pcs$0.92
- 10+ pcs$0.87
- 100+ pcs$0.82
- 500+ pcs$0.78
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Genişlik
- 19.4mm
- Weight
- 4.259998g
- Additional Feature
- PA, UL 94V0
- Özellikler
- Mating Flange
- Gerilim
- 300V
- Safety Approval
- UL
- Wire Gauge Min
- 24 AWG
- Terminal Stili
- Screw - Rising Cage Clamp
- Housing Material
- Polyamide (PA), Nylon
- Material Flammability Rating
- UL94 V-0
- Plug Wire Entry
- 180°
- Kurşunsuz Kodu
- yes
- REACH Uyumluluk Kodu
- not_compliant
- Ambalaj
- Bulk
- Connector Type
- Screw, Socket
- RoHS Durumu
- RoHS Compliant
- Akım Değeri
- 16A
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Strip Length
- 7mm
- Tip
- Plug, Female Sockets
- Pitch
- 0.197 5.00mm
- Parça Durumu
- Active
- Wire Gauge Max
- 12 AWG
- Number Of Decks
- 1
- Voltageiec
- 630V
- HTS Kodu
- 8536.69.40.40
- Number Of Levels
- 1
- Terminal
- Screw
- ECCN Kodu
- EAR99
- Insulation Height
- 0.591 15.00mm
- Contact Plating
- Tin
- Renk
- Green
- Montaj
- Free Hanging
- Uzunluk
- 15mm
- Sıra Sayısı
- 1
- Akım
- 16A
- Screw Size
- M3
- Gender
- Female
- Number Of Ways
- 2
- Yayın Yılı
- 2001
