Volume pricing
- 1+ pcs$11.71
- 10+ pcs$11.04
- 100+ pcs$10.42
- 500+ pcs$9.83
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Gerilim
- 300V
- Safety Approval
- UL
- Wire Gauge Min
- 24 AWG
- Terminal Stili
- Screwless - Leg Spring, Push-In Spring
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Polyamide (PA), Nylon
- Plug Wire Entry
- 180°
- Kurşunsuz Kodu
- yes
- Genişlik
- 70.02mm
- Weight
- 20.140012g
- Fastening Method
- SPRING LOADED
- Additional Feature
- PA, 94V-0
- Özellikler
- Mating Flange, Retention Latches (Non-Wire Side)
- RoHS Durumu
- RoHS Compliant
- Akım Değeri
- 12A
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Strip Length
- 10mm
- Wire Cross Section
- 2.5 mm2
- Ambalaj
- Bulk
- Connector Type
- Socket
- Currentiec
- 12A
- Terminal
- Screwless
- Pozisyon Sayısı
- 12
- Number Of Levels
- 1
- ECCN Kodu
- EAR99
- Insulation Height
- 0.591 15.00mm
- Renk
- Green
- Contact Plating
- Tin
- Tip
- Plug, Female Sockets
- Pitch
- 0.197 5.00mm
- Number Of Decks
- 1
- Wire Gauge Max
- 12 AWG
- Parça Durumu
- Active
- Voltageiec
- 630V
- HTS Kodu
- 8536.69.40.40
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- COMBICON FKC
- Montaj Tipi
- Free Hanging (In-Line)
- Yükseklik
- 25.6mm
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
