Volume pricing
- 1+ pcs$3.51
- 10+ pcs$3.32
- 100+ pcs$3.13
- 500+ pcs$2.95
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal
- Screwless
- Number Of Levels
- 1
- ECCN Kodu
- EAR99
- Insulation Height
- 0.591 15.00mm
- Contact Plating
- Tin
- Renk
- Green
- Number Of Contacts
- 10
- Tip
- Plug, Female Sockets
- Pitch
- 0.197 5.00mm
- Voltageiec
- 630V
- Parça Durumu
- Active
- Wire Gauge Max
- 12 AWG
- Number Of Decks
- 1
- HTS Kodu
- 8536.69.40.40
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- COMBICON FKC
- Montaj Tipi
- Free Hanging (In-Line)
- Orientation
- Straight
- Yükseklik
- 25.6mm
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Nominal Gerilim
- 250V
- Max Current Rating
- 12A
- Montaj
- Cable, Free Hanging
- Uzunluk
- 15mm
- Kurşunsuz
- Lead Free
- Sıra Sayısı
- 1
- Currentul
- 10A
- Akım
- 12A
- Number Of Ways
- 10
- Wire Gauge Or Range Awg
- 12-26 AWG
- Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2010
- Gerilim
- 300V
- Terminal Stili
- Screwless - Leg Spring, Push-In Spring
- Wire Gauge Min
- 24 AWG
- Safety Approval
- UL
- Housing Material
- Polyamide (PA), Nylon
- Material Flammability Rating
- UL94 V-0
- Kurşunsuz Kodu
- yes
- Plug Wire Entry
- 180°
