Volume pricing
- 1+ pcs$6.41
- 10+ pcs$6.04
- 100+ pcs$5.70
- 500+ pcs$5.38
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Plating
- Tin
- Renk
- Green
- Insulation Height
- 0.591 15.00mm
- Number Of Levels
- 1
- Terminal
- Screwless
- Pitch
- 0.197 5.00mm
- Voltageiec
- 630V
- Parça Durumu
- Active
- Wire Gauge Max
- 24 AWG
- Number Of Decks
- 1
- Number Of Contacts
- 9
- Tip
- Plug, Female Sockets
- Nominal Gerilim
- 250V
- Seri
- COMBICON FKC
- Material
- Polyamide
- Depth
- 15mm
- Montaj Tipi
- Free Hanging (In-Line)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Orientation
- Straight
- Yükseklik
- 25.6mm
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Number Of Ways
- 9
- Gender
- Female
- Akım
- 12A
- Wire Gauge Or Range Awg
- 12-26 AWG
- Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2010
- Uzunluk
- 45.1mm
- Montaj
- Cable, Free Hanging
- Max Current Rating
- 12A
- Currentul
- 10A
- Sıra Sayısı
- 1
- Kurşunsuz
- Lead Free
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Polyamide (PA), Nylon
- Terminal Stili
- Screwless - Leg Spring, Push-In Spring
- Wire Gauge Min
- 12 AWG
- Safety Approval
- UL
- Kurşunsuz Kodu
- yes
- Plug Wire Entry
- 180°
