Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yayın Yılı
- 2011
- Wire Gauge Or Range Awg
- 12-26 AWG
- Flammability Rating
- UL94 V-0
- Ambalaj
- Bulk
- Akım
- 10A
- Number Of Ways
- 10
- Sıra Sayısı
- 1
- Wire Cross Section
- 2.5 mm2
- Montaj
- Free Hanging
- Fabrika Tedarik Süresi
- 5 Weeks
- Wire Strip Length
- 10mm
- RoHS Durumu
- RoHS Compliant
- Nominal Gerilim
- 250V
- Akım Değeri
- 12A
- Contact Mating Finish
- Tin
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Free Hanging (In-Line)
- Seri
- COMBICON FKCVW
- Number Of Decks
- 1
- Wire Gauge Max
- 12 AWG
- Parça Durumu
- Active
- Voltageiec
- 630V
- Özellikler
- Retention Latches (Non-Wire Side)
- HTS Kodu
- 8536.69.40.40
- Pitch
- 0.197 5.00mm
- Weight
- 16.089999g
- Fastening Method
- SPRING LOADED
- Additional Feature
- PA, UL 94V-0
- Tip
- Plug, Female Sockets
- Insulation Height
- 0.661 16.80mm
- Plug Wire Entry
- 270°
- Kurşunsuz Kodu
- yes
- Renk
- Green
- Safety Approval
- UL
- Terminal Stili
- Screwless - Leg Spring, Push-In Spring
- ECCN Kodu
- EAR99
- Wire Gauge Min
- 24 AWG
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Polyamide (PA), Nylon
