Volume pricing
- 1+ pcs$15.69
- 10+ pcs$14.81
- 100+ pcs$13.97
- 500+ pcs$13.18
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Additional Feature
- PA, 94V-0
- Pozisyon Sayısı
- 14
- Terminal Stili
- Screwless - Leg Spring, Push-In Spring
- Renk
- Green
- Contact Mating Finish
- Tin
- Seri
- COMBICON FKCT
- Number Of Decks
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Ways
- 14
- Nominal Gerilim
- 250V
- Insulation Height
- 0.591 15.00mm
- Safety Approval
- UL
- Number Of Levels
- 1
- Akım
- 10A
- Fabrika Tedarik Süresi
- 4 Weeks
- Wire Cross Section
- 2.5 mm2
- Parça Durumu
- Active
- Gerilim
- 300V
- Terminal
- Screwless
- HTS Kodu
- 8536.69.40.40
- Wire Gauge Or Range Awg
- 12-26 AWG
- Material Flammability Rating
- UL94 V-0
- Kurşunsuz Kodu
- yes
- Sıra Sayısı
- 1
- Fastening Method
- SPRING LOADED
- Yayın Yılı
- 2003
- Flammability Rating
- UL94 V-0
- Özellikler
- Retention Latches (Non-Wire Side)
- Wire Gauge Min
- 24 AWG
- Wire Strip Length
- 10mm
- Pitch
- 0.200 5.08mm
- Montaj
- Free Hanging
- ECCN Kodu
- EAR99
- Currentiec
- 12A
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Tip
- Plug, Female Sockets
- Plug Wire Entry
- 180°
- Voltageiec
- 630V
- Weight
- 23.069991g
- Montaj Tipi
- Free Hanging (In-Line)
