Specifications
- RoHS Durumu
- RoHS Compliant
- Number Of Ways
- 7
- Pitch
- 0.150 3.81mm
- Tip
- Plug, Female Sockets
- Insulation Height
- 0.508 12.90mm
- Uzunluk
- 37.1mm
- Nominal Gerilim
- 200V
- Seri
- COMBICON QC
- Terminal Stili
- IDC
- Voltageiec
- 400V
- Özellikler
- Mating Flange
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Polyamide (PA), Nylon
- Material
- Polyamide, Tin
- Number Of Decks
- 1
- Wire Cross Section
- 0.5 mm2
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Sıra Sayısı
- 1
- Montaj
- Free Hanging
- Wire Gauge Or Range Mm
- 0.34-0.5mm2
- Gender
- Female
- Wire Gauge Min
- 22 AWG
- Connector Type
- IDC, IDT
- Wire Gauge Max
- 20 AWG
- Kurşunsuz Kodu
- yes
- Number Of Positions Per Level
- 7
- Flammability Rating
- UL94 V-0
- Plug Wire Entry
- 180°
- Akım
- 6A
- Additional Feature
- PA, 94V-0
- Wire Gauge Or Range Awg
- 20-24 AWG
- Safety Approval
- UL
- Yükseklik
- 12.9mm
- Contact Mating Finish
- Tin
- Weight
- 96.999991g
- Akım Değeri
- 6A
- Genişlik
- 22.3mm
- HTS Kodu
- 8536.69.40.40
- Montaj Tipi
- Free Hanging (In-Line)
