Volume pricing
- 1+ pcs$12.12
- 10+ pcs$11.43
- 100+ pcs$10.79
- 500+ pcs$10.18
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- RoHS Compliant
- Number Of Ways
- 8
- Pitch
- 0.150 3.81mm
- Tip
- Plug, Female Sockets
- Insulation Height
- 0.508 12.90mm
- Uzunluk
- 31.27mm
- Max Supply Voltage
- 160V
- Seri
- COMBICON QC
- Nominal Gerilim
- 200V
- Max Current Rating
- 8A
- Terminal Stili
- IDC
- Voltageiec
- 400V
- Housing Material
- Polyamide (PA), Nylon
- Material Flammability Rating
- UL94 V-0
- Material
- Polyamide, Tin
- REACH Uyumluluk Kodu
- unknown
- Number Of Decks
- 1
- Wire Cross Section
- 0.34 mm2
- Depth
- 22.3mm
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Sıra Sayısı
- 1
- Montaj
- Free Hanging
- Wire Gauge Or Range Mm
- 0.34-0.5mm2
- Gender
- Female
- Wire Gauge Min
- 20 AWG
- Orientation
- Right Angle
- Connector Type
- IDC, IDT
- Wire Gauge Max
- 24 AWG
- Number Of Positions Per Level
- 8
- Kurşunsuz Kodu
- yes
- Flammability Rating
- UL94 V-0
- Plug Wire Entry
- 180°
- Akım
- 6A
- Additional Feature
- PA, UL 94V0
- Wire Gauge Or Range Awg
- 20-24 AWG
- Safety Approval
- UL
- Weight
- 96.999991g
- Contact Mating Finish
- Tin
- Akım Değeri
- 6A
