Volume pricing
- 1+ pcs$0.33
- 10+ pcs$0.31
- 100+ pcs$0.29
- 500+ pcs$0.28
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Ways
- 2
- Housing Material
- Polyamide (PA), Nylon
- Akım Değeri
- 4A
- Genişlik
- 8.1mm
- Yükseklik
- 8.1mm
- Insulation Height
- 0.398 10.11mm
- Renk
- Green
- Nominal Gerilim
- 80V
- Wire Gauge Min
- 26 AWG
- Number Of Decks
- 1
- ECCN Kodu
- EAR99
- Material
- Polyamide
- Depth
- 8.1mm
- Kurşunsuz
- Lead Free
- Max Current Rating
- 4A
- Number Of Poles
- 2
- Additional Feature
- STANDARD: UL 94V-0, PA
- Weight
- 489.993158mg
- Ambalaj
- Bulk
- Contact Tail Length
- 0.138 3.50mm
- Terminal Stili
- Solder
- Sıra Sayısı
- 1
- Uzunluk
- 6.9mm
- Voltageiec
- 320V
- Yayın Yılı
- 2010
- Akım
- 4A
- Kurşunsuz Kodu
- yes
- Fabrika Tedarik Süresi
- 7 Weeks
- Orientation
- Straight
- Fastening Method
- CONNECTOR
- Wire Gauge Max
- 20 AWG
- Contact Plating
- Tin
- Connector Type
- Plug
- Material Flammability Rating
- UL94 V-0
- Safety Approval
- CB; CCA; CUL; EAC; UL; VDE
- Flammability Rating
- UL94 V-0
- Header Orientation
- Vertical
- RoHS Durumu
- RoHS Compliant
- Gender
- Male
- Pitch
- 0.098 2.50mm
