Volume pricing
- 1+ pcs$6.50
- 10+ pcs$6.13
- 100+ pcs$5.78
- 500+ pcs$5.45
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material
- Polyamide
- Fabrika Tedarik Süresi
- 4 Weeks
- Depth
- 16.8mm
- Kurşunsuz Kodu
- yes
- Wire Gauge Max
- 12 AWG
- Number Of Decks
- 1
- Terminal
- Screwless
- Sıra Sayısı
- 1
- Wire Strip Length
- 10mm
- Connector Type
- Socket
- Additional Feature
- PA, UL 94V-0
- Özellikler
- Mating Flange, Retention Latches (Non-Wire Side)
- Orientation
- Right Angle
- Housing Material
- Polyamide (PA), Nylon
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Height
- 0.661 16.80mm
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Montaj Tipi
- Free Hanging (In-Line)
- Gender
- Female
- Max Current Rating
- 12A
- Wire Gauge Or Range Awg
- 12-26 AWG
- Fastening Method
- SPRING LOADED
- Number Of Levels
- 1
- Voltageiec
- 630V
- Flammability Rating
- UL94 V-0
- Ambalaj
- Bulk
- RoHS Durumu
- RoHS Compliant
- Number Of Ways
- 6
- Plug Wire Entry
- 90°
- Gerilim
- 300V
- Uzunluk
- 40.58mm
- Akım Değeri
- 12A
- Montaj
- Cable, Free Hanging, Panel
- Yükseklik
- 26.6mm
- Tip
- Plug, Female Sockets
- Terminal Stili
- Screwless - Leg Spring, Push-In Spring
- Safety Approval
- UL
- Contact Plating
- Tin
- Seri
- COMBICON FKCVR
- Renk
- Green
