Volume pricing
- 1+ pcs$10.33
- 10+ pcs$9.74
- 100+ pcs$9.19
- 500+ pcs$8.67
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Özellikler
- Mating Flange, Retention Latches (Non-Wire Side)
- Pozisyon Sayısı
- 8
- Renk
- Green
- Additional Feature
- PA, UL 94V-0
- Seri
- COMBICON FKCVW
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Mating Finish
- Tin
- Housing Material
- Polyamide (PA), Nylon
- Wire Cross Section
- 2.5 mm2
- Akım
- 10A
- Pitch
- 0.200 5.08mm
- Parça Durumu
- Active
- Wire Gauge Min
- 12 AWG
- Weight
- 14.359997g
- Montaj Tipi
- Free Hanging (In-Line)
- Nominal Gerilim
- 250V
- ECCN Kodu
- EAR99
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Insulation Height
- 0.661 16.80mm
- Fastening Method
- SPRING LOADED
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Awg
- 12-26 AWG
- Yayın Yılı
- 2011
- Voltageiec
- 630V
- Number Of Levels
- 1
- Fabrika Tedarik Süresi
- 4 Weeks
- Currentiec
- 12A
- Number Of Ways
- 8
- Ambalaj
- Bulk
- RoHS Durumu
- RoHS Compliant
- Flammability Rating
- UL94 V-0
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 12A
- Number Of Decks
- 1
- Gerilim
- 300V
- Wire Gauge Max
- 26 AWG
- Plug Wire Entry
- 270°
- Wire Strip Length
- 10mm
- Terminal Stili
- Screwless - Leg Spring, Push-In Spring
- Sıra Sayısı
- 1
