Volume pricing
- 1+ pcs$0.73
- 10+ pcs$0.69
- 100+ pcs$0.65
- 500+ pcs$0.62
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj Tipi
- Free Hanging (In-Line)
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Insulation Height
- 0.591 15.00mm
- Gender
- Female
- Wire Gauge Or Range Awg
- 12-26 AWG
- Max Current Rating
- 12A
- Fastening Method
- SPRING LOADED
- Connector Type
- Socket
- Özellikler
- Mating Flange, Retention Latches (Non-Wire Side)
- Additional Feature
- PA, 94V-0
- Orientation
- Straight
- Housing Material
- Polyamide (PA), Nylon
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Mating Finish
- Tin
- Max Supply Voltage
- 250V
- Number Of Decks
- 1
- Wire Gauge Max
- 26 AWG
- Terminal
- Screwless
- Wire Strip Length
- 10mm
- Sıra Sayısı
- 1
- Fabrika Tedarik Süresi
- 7 Weeks
- Material
- Polyamide, Tin
- Kurşunsuz Kodu
- yes
- Depth
- 25.6mm
- Kurşunsuz
- Lead Free
- Nominal Gerilim
- 250V
- ECCN Kodu
- EAR99
- Akım
- 10A
- Parça Durumu
- Active
- Pitch
- 0.200 5.08mm
- Wire Gauge Min
- 12 AWG
- Weight
- 4.859987g
- Yayın Yılı
- 2011
- HTS Kodu
- 8536.69.40.40
- Genişlik
- 25.6mm
- Material Flammability Rating
- UL94 V-0
- Seri
- COMBICON FKC
- Renk
- Green
- Akım Değeri
- 12A
- Uzunluk
- 20.26mm
