Volume pricing
- 1+ pcs$2.78
- 10+ pcs$2.62
- 100+ pcs$2.48
- 500+ pcs$2.34
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Or Range Awg
- 12-26 AWG
- Fastening Method
- SPRING LOADED
- Montaj Tipi
- Free Hanging (In-Line)
- Insulation Height
- 0.591 15.00mm
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Housing Material
- Polyamide (PA), Nylon
- Contact Mating Finish
- Tin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Retention Latches (Non-Wire Side)
- Additional Feature
- PA, UL 94V-0
- Terminal
- Screwless
- Wire Strip Length
- 10mm
- Sıra Sayısı
- 1
- Number Of Decks
- 1
- Wire Gauge Max
- 12 AWG
- Kurşunsuz Kodu
- yes
- Kurşunsuz
- Lead Free
- Currentiec
- 12A
- Fabrika Tedarik Süresi
- 4 Weeks
- Yayın Yılı
- 2003
- HTS Kodu
- 8536.69.40.40
- Genişlik
- 56.5mm
- Material Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 250V
- ECCN Kodu
- EAR99
- Akım
- 10A
- Parça Durumu
- Active
- Pitch
- 0.200 5.08mm
- Weight
- 138.000007g
- Wire Gauge Min
- 24 AWG
- Wire Cross Section
- 2.5 mm2
- Seri
- COMBICON FKC
- Pozisyon Sayısı
- 11
- Renk
- Green
- Montaj
- Free Hanging
- Yükseklik
- 15mm
- Tip
- Plug, Female Sockets
- Safety Approval
- CB; CCA; CUL; GOST; UL; VDE
- Terminal Stili
- Screwless - Leg Spring, Push-In Spring
- Uzunluk
- 56.5mm
