Volume pricing
- 1+ pcs$1.27
- 10+ pcs$1.20
- 100+ pcs$1.13
- 500+ pcs$1.06
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Flammability Rating
- UL94 V-0
- Housing Material
- Polyamide (PA), Nylon
- Weight
- 6.819988g
- Onay Kuruluşu
- CB, CSA, UL, cULus
- Parça Durumu
- Active
- Seri
- COMBICON SMKDSN
- Material
- Polyamide
- Montaj Tipi
- Through Hole
- Fabrika Tedarik Süresi
- 7 Weeks
- Max Supply Voltage
- 250V
- Screw Thread
- M3
- Yükseklik
- 14.5mm
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Stripping Length
- 6mm
- Safety Approval
- UL
- Montaj
- Through Hole
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Kurşunsuz
- Lead Free
- Wire Gauge Max
- 30 AWG
- REACH Uyumluluk Kodu
- unknown
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2012
- Gerilim
- 300V
- Number Of Decks
- 1
- Wire Termination
- Screw - Rising Cage Clamp
- Depth
- 12mm
- Orientation
- Straight
- Mating Orientation
- 55° (125°) Angle with Board
- Insulation Materials
- Nylon
- Max Current Rating
- 13.5A
- Akım
- 10A
- Contact Materials
- Tin
- Number Of Levels
- 1
- Number Of Ways
- 6
- Renk
- Green
- Connector Type
- Screw
- Wire Gauge Min
- 14 AWG
- Ambalaj
- Bulk
- Genişlik
- 31mm
