Volume pricing
- 1+ pcs$2.47
- 10+ pcs$2.33
- 100+ pcs$2.20
- 500+ pcs$2.07
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Gerilim
- 300V
- Seri
- COMBICON MCVW
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Awg
- 14-30 AWG
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Akım
- 8A
- Number Of Ways
- 8
- Plug Wire Entry
- 270°
- ECCN Kodu
- EAR99
- Voltageiec
- 320V
- Safety Approval
- UL
- Montaj Tipi
- Free Hanging (In-Line)
- Screw Size
- M2
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Max
- 30 AWG
- Contact Mating Finish
- Tin
- Number Of Decks
- 1
- Terminal Stili
- Screw - Rising Cage Clamp
- Kurşunsuz Kodu
- yes
- Fabrika Tedarik Süresi
- 4 Weeks
- Nominal Gerilim
- 160V
- Pozisyon Sayısı
- 8
- Insulation Height
- 0.752 19.10mm
- Renk
- Green
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım Değeri
- 8A
- Yayın Yılı
- 2011
- Housing Material
- Polyamide (PA), Nylon
- Sıra Sayısı
- 1
- Weight
- 6.920005g
- Pitch
- 0.138 3.50mm
- Tip
- Plug, Female Sockets
- Montaj
- Free Hanging
- Özellikler
- Mating Flange
- Ambalaj
- Bulk
- Additional Feature
- PA, 94V-0
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Connector Type
- Screw
- Wire Strip Length
- 7mm
