Volume pricing
- 1+ pcs$2.08
- 10+ pcs$1.96
- 100+ pcs$1.85
- 500+ pcs$1.75
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Özellikler
- Mating Flange
- Terminal
- Screw
- Montaj
- Free Hanging
- Ambalaj
- Bulk
- Additional Feature
- PA, 94V-0
- Contact Plating
- Tin
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Connector Type
- Screw, Socket
- Wire Strip Length
- 7mm
- Number Of Levels
- 1
- Wire Gauge Min
- 28 AWG
- Yükseklik
- 19.1mm
- Insulation Height
- 0.752 19.10mm
- Akım Değeri
- 8A
- Renk
- Green
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Polyamide (PA), Nylon
- Yayın Yılı
- 2011
- Sıra Sayısı
- 1
- Weight
- 5.3g
- Pitch
- 0.138 3.50mm
- Tip
- Plug, Female Sockets
- Safety Approval
- UL
- Screw Size
- M2
- Montaj Tipi
- Free Hanging (In-Line)
- Wire Gauge Max
- 16 AWG
- Material Flammability Rating
- UL94 V-0
- Number Of Decks
- 1
- Kurşunsuz Kodu
- yes
- Genişlik
- 31.4mm
- Terminal Stili
- Screw - Rising Cage Clamp
- Pozisyon Sayısı
- 6
- Nominal Gerilim
- 160V
- Fabrika Tedarik Süresi
- 4 Weeks
- Seri
- COMBICON MCVW
- Gerilim
- 300V
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Awg
- 14-30 AWG
- Akım
- 8A
