Volume pricing
- 1+ pcs$1.54
- 10+ pcs$1.46
- 100+ pcs$1.37
- 500+ pcs$1.30
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Uzunluk
- 18.3mm
- Number Of Ways
- 5
- ECCN Kodu
- EAR99
- Voltageiec
- 320V
- Gerilim
- 300V
- Kurşunsuz
- Lead Free
- Flammability Rating
- UL94 V-0
- Insulation Materials
- Nylon
- Depth
- 10.4mm
- Stripping Length
- 7mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Onay Kuruluşu
- CB, UL, VDE, cULus
- Number Of Contacts
- 5
- Wire Gauge Max
- 16 AWG
- Material Flammability Rating
- UL94 V-0
- Gender
- Female
- Tip
- Plug, Female Sockets
- Max Current Rating
- 8A
- Yükseklik
- 12.5mm
- Insulation Height
- 0.752 19.10mm
- Radyasyon Dayanımı
- No
- RoHS Durumu
- RoHS Compliant
- Number Of Levels
- 1
- Wire Gauge Min
- 28 AWG
- Orientation
- Straight
- Montaj
- Cable, Free Hanging
- Contact Plating
- Tin
- Akım
- 8A
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Voltage Rated Dc
- 160V
- Plug Wire Entry
- 270°
- Voltage Rated Ac
- 160V
- Seri
- COMBICON MCVW
- Wire Gauge Or Range Awg
- 14-30 AWG
- Number Of Decks
- 1
- Genişlik
- 19.1mm
- Kurşunsuz Kodu
- yes
- Terminal Stili
- Screw - Rising Cage Clamp
- Safety Approval
- UL
- Screw Size
- M2
