Volume pricing
- 1+ pcs$0.75
- 10+ pcs$0.70
- 100+ pcs$0.66
- 500+ pcs$0.63
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- ECCN Kodu
- EAR99
- Voltageiec
- 320V
- Uzunluk
- 7.8mm
- Number Of Ways
- 2
- Kurşunsuz
- Lead Free
- Flammability Rating
- UL94 V-0
- Gerilim
- 300V
- Fabrika Tedarik Süresi
- 7 Weeks
- Depth
- 10.4mm
- Insulation Materials
- Nylon
- HTS Kodu
- 8536.69.40.40
- Stripping Length
- 7mm
- Wire Gauge Max
- 30 AWG
- Number Of Contacts
- 2
- Material Flammability Rating
- UL94 V-0
- Gender
- Female
- Onay Kuruluşu
- UL, VDE
- Tip
- Plug, Female Sockets
- Reach Svhc
- No SVHC
- Max Current Rating
- 8A
- Yükseklik
- 12.5mm
- Insulation Height
- 0.752 19.10mm
- Number Of Levels
- 1
- Wire Gauge Min
- 14 AWG
- Orientation
- Straight
- RoHS Durumu
- RoHS Compliant
- Contact Plating
- Tin
- Montaj
- Cable, Free Hanging
- Akım
- 8A
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Voltage Rated Dc
- 160V
- Plug Wire Entry
- 270°
- Wire Gauge Or Range Awg
- 14-30 AWG
- Voltage Rated Ac
- 160V
- Seri
- COMBICON MCVW
- Number Of Decks
- 1
- Genişlik
- 19.1mm
- Kurşunsuz Kodu
- yes
- Terminal Stili
- Screw - Rising Cage Clamp
- Safety Approval
- UL; CSA
