Volume pricing
- 1+ pcs$1.35
- 10+ pcs$1.27
- 100+ pcs$1.20
- 500+ pcs$1.13
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Insulation Height
- 0.591 15.00mm
- REACH Uyumluluk Kodu
- not_compliant
- Wire Strip Length
- 7mm
- Wire Gauge Max
- 30 AWG
- Pozisyon Sayısı
- 2
- Kurşunsuz
- Lead Free
- Terminal Stili
- Screw - Rising Cage Clamp
- Parça Durumu
- Active
- Voltageiec
- 1kV
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Flammability Rating
- UL94 V-0
- Contact Plating
- Tin
- RoHS Durumu
- RoHS Compliant
- Gerilim
- 300V
- Number Of Ways
- 2
- Weight
- 167.00001g
- Housing Material
- Polyamide (PA), Nylon
- Renk
- Green
- Number Of Levels
- 1
- Kurşunsuz Kodu
- yes
- Özellikler
- Mating Flange
- Tip
- Plug, Female Sockets
- Yayın Yılı
- 2012
- Genişlik
- 25.63mm
- Pitch
- 0.300 7.62mm
- Yükseklik
- 18.2mm
- HTS Kodu
- 8536.69.40.40
- Akım Değeri
- 12A
- Uzunluk
- 15mm
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Screw Size
- M3
- Connector Type
- Screw, Socket
- Akım
- 10A
- Material Flammability Rating
- UL94 V-0
- Ambalaj
- Bulk
- Montaj Tipi
- Free Hanging (In-Line)
- Montaj
- Free Hanging
- Nominal Gerilim
- 400V
- Seri
- COMBICON GMSTB
- Wire Gauge Or Range Awg
- 12-30 AWG
