Volume pricing
- 1+ pcs$18.61
- 10+ pcs$17.56
- 100+ pcs$16.56
- 500+ pcs$15.63
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Renk
- Green
- Sıra Sayısı
- 1
- Weight
- 11.42001g
- Housing Material
- Polyamide (PA), Nylon
- Number Of Ways
- 14
- Gerilim
- 300V
- Tip
- Plug, Male Pins
- Özellikler
- Mating Flange
- Safety Approval
- UL
- Kurşunsuz Kodu
- yes
- Number Of Levels
- 1
- Wire Strip Length
- 7mm
- Wire Gauge Max
- 30 AWG
- Insulation Height
- 0.437 11.10mm
- REACH Uyumluluk Kodu
- unknown
- RoHS Durumu
- RoHS Compliant
- Flammability Rating
- UL94 V-0
- Max Current Rating
- 8A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltageiec
- 320V
- Parça Durumu
- Active
- Number Of Decks
- 1
- Terminal Stili
- Screw - Rising Cage Clamp
- Contact Mating Finish
- Tin
- Seri
- COMBICON IMC
- Wire Gauge Or Range Awg
- 14-30 AWG
- Nominal Gerilim
- 160V
- Montaj
- Free Hanging, Panel
- Montaj Tipi
- Free Hanging (In-Line)
- Ambalaj
- Bulk
- Material Flammability Rating
- UL94 V-0
- Orientation
- Right Angle
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 7 Weeks
- Wire Gauge Min
- 14 AWG
- Plug Wire Entry
- 180°
- HTS Kodu
- 8536.69.40.40
- Pitch
- 0.150 3.81mm
- Additional Feature
- PA, 94V-0
- Yayın Yılı
- 2011
