Volume pricing
- 1+ pcs$14.78
- 10+ pcs$13.94
- 100+ pcs$13.15
- 500+ pcs$12.41
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pitch
- 0.150 3.81mm
- Yayın Yılı
- 2008
- Genişlik
- 38.89mm
- Additional Feature
- PA, 94V-0
- Material
- Polyamide
- Akım
- 8A
- Number Of Contacts
- 10
- Stripping Length
- 7mm
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Montaj Tipi
- Free Hanging (In-Line)
- Montaj
- Cable, Free Hanging
- Nominal Gerilim
- 160V
- Seri
- COMBICON IMC
- Wire Gauge Or Range Awg
- 14-30 AWG
- Orientation
- Right Angle
- Material Flammability Rating
- UL94 V-0
- Depth
- 17.9mm
- ECCN Kodu
- EAR99
- Plug Wire Entry
- 180°
- Flammability Rating
- UL94 V-0
- Contact Plating
- Tin
- RoHS Durumu
- RoHS Compliant
- Number Of Decks
- 1
- Terminal Stili
- Screw - Rising Cage Clamp
- Voltageiec
- 320V
- Weight
- 102.999998g
- Sıra Sayısı
- 1
- Renk
- Green
- Gerilim
- 300V
- Number Of Levels
- 1
- Kurşunsuz Kodu
- yes
- Safety Approval
- UL
- Max Supply Voltage
- 160V
- Yükseklik
- 17.9mm
- HTS Kodu
- 8536.69.40.40
- Connector Type
- Plug, Screw
- Akım Değeri
- 8A
- Uzunluk
- 38.89mm
- Screw Size
- M2
- Ambalaj
- Bulk
