Specifications
- Gerilim
- 300V
- Renk
- Green
- Sıra Sayısı
- 1
- Weight
- 102.999998g
- Safety Approval
- UL
- Max Supply Voltage
- 160V
- Kurşunsuz Kodu
- yes
- Number Of Levels
- 1
- Wire Strip Length
- 7mm
- Voltageiec
- 320V
- Number Of Decks
- 1
- Terminal Stili
- Screw - Rising Cage Clamp
- RoHS Durumu
- RoHS Compliant
- Contact Plating
- Tin
- Flammability Rating
- UL94 V-0
- Material Flammability Rating
- UL94 V-0
- Orientation
- Right Angle
- Seri
- COMBICON IMC
- Wire Gauge Or Range Awg
- 14-30 AWG
- Nominal Gerilim
- 160V
- Montaj
- Cable, Free Hanging
- Montaj Tipi
- Free Hanging (In-Line)
- Plug Wire Entry
- 180°
- ECCN Kodu
- EAR99
- Depth
- 17.9mm
- Additional Feature
- PA, 94V-0
- Genişlik
- 17.9mm
- Yayın Yılı
- 2010
- Pitch
- 0.150 3.81mm
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Number Of Contacts
- 3
- Akım
- 8A
- Material
- Polyamide
- Number Of Ways
- 3
- Housing Material
- Polyamide (PA), Nylon
- Tip
- Plug, Male Pins
- Insulation Height
- 0.437 11.10mm
- Wire Gauge Max
- 16 AWG
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
