Volume pricing
- 1+ pcs$2.11
- 10+ pcs$1.99
- 100+ pcs$1.88
- 500+ pcs$1.77
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Max Current Rating
- 8A
- Number Of Decks
- 1
- RoHS Durumu
- RoHS Compliant
- Wire Strip Length
- 9mm
- Number Of Levels
- 1
- Montaj Tipi
- Free Hanging (In-Line)
- Number Of Contacts
- 4
- Genişlik
- 21.7mm
- REACH Uyumluluk Kodu
- unknown
- Seri
- COMBICON FRONT-MC
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Depth
- 21.7mm
- Kurşunsuz Kodu
- yes
- Renk
- Green
- Number Of Ways
- 4
- Screw Size
- M2
- Kurşunsuz
- Lead Free
- Gerilim
- 300V
- Yayın Yılı
- 2012
- Max Supply Voltage
- 160V
- Wire Gauge Max
- 30 AWG
- Weight
- 98.999993g
- Terminal Stili
- Screw - Pressure Clip
- Özellikler
- Mating Flange
- Orientation
- Straight
- Akım
- 8A
- Yükseklik
- 21.7mm
- Flammability Rating
- UL94 V-0
- Wire Gauge Min
- 16 AWG
- Terminal
- Screw
- Plug Wire Entry
- 180°
- Sıra Sayısı
- 1
- Tip
- Plug, Female Sockets
- Housing Material
- Polyamide (PA), Nylon
- Material
- Polyamide
- Akım Değeri
- 8A
- Contact Plating
- Tin
- Nominal Gerilim
- 160V
