Volume pricing
- 1+ pcs$1.10
- 10+ pcs$1.03
- 100+ pcs$0.98
- 500+ pcs$0.92
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Plating
- Tin
- Material
- Polyamide
- Terminal Stili
- Screw - Rising Cage Clamp
- Orientation
- Straight
- Tip
- Plug, Female Sockets
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2010
- Parça Durumu
- Active
- Number Of Decks
- 1
- Connector Type
- Screw, Socket
- Wire Gauge Min
- 28 AWG
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Montaj
- Cable, Free Hanging
- Insulation Height
- 0.437 11.10mm
- Flammability Rating
- UL94 V-0
- Number Of Ways
- 3
- Seri
- COMBICON MC
- Uzunluk
- 24.44mm
- Wire Gauge Max
- 16 AWG
- RoHS Durumu
- RoHS Compliant
- Depth
- 11.1mm
- Safety Approval
- UL; CSA
- Number Of Levels
- 1
- Renk
- Green
- Yükseklik
- 15.5mm
- Pitch
- 0.200 5.08mm
- Fabrika Tedarik Süresi
- 11 Weeks
- Voltageiec
- 400V
- ECCN Kodu
- EAR99
- Akım
- 8A
- Terminal
- Screw
- Onay Kuruluşu
- CB, CSA, VDE, cULus
- Montaj Tipi
- Free Hanging (In-Line)
- Akım Değeri
- 8A
- Genişlik
- 15.5mm
- Material Flammability Rating
- UL94 V-0
- Number Of Positions Per Level
- 3
- Wire Gauge Or Range Awg
- 14-30 AWG
- Ambalaj
- Bulk
- Nominal Gerilim
- 250V
