Volume pricing
- 1+ pcs$9.36
- 10+ pcs$8.83
- 100+ pcs$8.33
- 500+ pcs$7.86
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yükseklik
- 26.2mm
- Voltageiec
- 320V
- Genişlik
- 21.9mm
- Connector Type
- Plug
- Parça Durumu
- Active
- HTS Kodu
- 8536.69.40.40
- Ambalaj
- Bulk
- Max Current Rating
- 8A
- Montaj Tipi
- Through Hole
- Contact Materials
- Copper
- Pozisyon Sayısı
- 20
- Orientation
- Right Angle
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Number Of Levels
- 2
- Material Flammability Rating
- UL94 V-0
- Additional Feature
- PBT, 94V-0
- Uzunluk
- 39.49mm
- Akım
- 8A
- Header Orientation
- 90°, Right Angle
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Weight
- 117.000013g
- Terminal Stili
- Solder
- Renk
- Green
- Safety Approval
- UL
- Yayın Yılı
- 2011
- Number Of Positions Per Level
- 10
- Montaj
- Through Hole
- Housing Material
- Polyamide (PA), Nylon
- Tip
- Header, Male Pins, Shrouded (4 Side)
- Fabrika Tedarik Süresi
- 7 Weeks
- Nominal Gerilim
- 160V
- Flammability Rating
- UL94 V-0
- Akım Değeri
- 8A
- Number Of Decks
- 1
- RoHS Durumu
- RoHS Compliant
- Sıra Sayısı
- 1
- Contact Tail Length
- 0.138 3.50mm
- Gerilim
- 300V
- Insulation Height
- 0.894 22.71mm
