Volume pricing
- 1+ pcs$6.98
- 10+ pcs$6.58
- 100+ pcs$6.21
- 500+ pcs$5.86
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- RoHS Compliant
- Gerilim
- 600V
- Renk
- Green
- Akım Değeri
- 20A
- Safety Approval
- UL
- Wire Gauge Max
- 10 AWG
- Stripping Length
- 7mm
- Wire Cross Section
- 4 mm2
- Additional Feature
- PA, 94V-0
- Montaj
- Panel, Wall
- Flammability Rating
- UL94 V-2
- Front Panel Wire Connection
- Header, Male Pins
- Housing Material
- Polyamide
- Max Supply Voltage
- 400V
- Özellikler
- Threaded Mating Lock
- Wire Gauge
- 10-30 AWG
- Yükseklik
- 32mm
- Number Of Contacts
- 8
- Depth
- 32mm
- ECCN Kodu
- EAR99
- Number Of Levels
- 1
- Wire Gauge Min
- 24 AWG
- Contact Materials
- Tin
- Terminal
- Screw
- Number Of Decks
- 1
- Parça Durumu
- Active
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Connector Type
- Plug
- Panel Thickness
- 0.039 ~ 0.197 1.0 ~ 5.0mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Gender
- Female
- Kurşunsuz Kodu
- yes
- Rear Panel Wire Connection
- Bolt/Screw Clamp - Wire Entry Parallel to Panel
- Nominal Gerilim
- 400V
- Orientation
- Right Angle
- Yayın Yılı
- 2003
- Sıra Sayısı
- 1
- Uzunluk
- 82.58mm
- Genişlik
- 3.251 82.58mm
- Akım
- 35A
