Specifications
- Flammability Rating
- UL94 V-0
- Number Of Ways
- 2
- Yükseklik
- 10.16mm
- Fastening Method
- CONNECTOR
- Number Of Positions Per Level
- 2
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Tip
- Header, Male Pins, Shrouded (4 Side)
- Contact Mating Finish
- Tin
- Genişlik
- 12.6mm
- Material Flammability Rating
- UL94 V-0
- Parça Durumu
- Active
- Number Of Decks
- 1
- Safety Approval
- CCA; CB; CSA; CUL; GOST; UL
- Yayın Yılı
- 2010
- Housing Material
- Polybutylene Terephthalate (PBT)
- Pitch
- 0.200 5.08mm
- Uzunluk
- 10.16mm
- Akım
- 8A
- Header Orientation
- Vertical
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Akım Değeri
- 8A
- Seri
- COMBICON MCV
- Weight
- 122.999991g
- Contact Tail Length
- 0.134 3.40mm
- Ambalaj
- Bulk
- Connector Type
- Plug
- Terminal Stili
- Solder
- Additional Feature
- PBT, UL 94V-0, LOW PROFILE, SAFETY APPROVAL VDE
- Gerilim
- 300V
- Contact Materials
- Copper, Tin
- Nominal Gerilim
- 250V
- Kurşunsuz Kodu
- yes
- Renk
- Green
- Max Current Rating
- 8A
- Voltageiec
- 400V
- Fabrika Tedarik Süresi
- 4 Weeks
- Montaj
- Through Hole
- Insulation Height
- 0.362 9.20mm
