Volume pricing
- 1+ pcs$3.01
- 10+ pcs$2.84
- 100+ pcs$2.68
- 500+ pcs$2.53
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Decks
- 1
- Yayın Yılı
- 2011
- Housing Material
- Polyamide (PA), Nylon
- Pozisyon Sayısı
- 10
- Pitch
- 0.200 5.08mm
- RoHS Durumu
- RoHS Compliant
- Genişlik
- 60.96mm
- Contact Plating
- Tin
- Parça Durumu
- Active
- Renk
- Green
- Nominal Gerilim
- 250V
- Wire Gauge Max
- 30 AWG
- Sıra Sayısı
- 1
- Fabrika Tedarik Süresi
- 4 Weeks
- Terminal
- Screw
- Voltageiec
- 630V
- Currentul
- 15A
- Plug Wire Entry
- 90°
- Seri
- COMBICON MVSTBR
- Wire Gauge Or Range Awg
- 12-30 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Wire Strip Length
- 7mm
- Ambalaj
- Bulk
- Weight
- 133.000002g
- Connector Type
- Screw, Socket
- Safety Approval
- UL
- Özellikler
- Mating Flange, Retention Latches (Wire Side)
- Wire Gauge Min
- 12 AWG
- Wire Cross Section
- 2.5 mm2
- Uzunluk
- 12.6mm
- Yükseklik
- 26mm
- Number Of Ways
- 10
- Flammability Rating
- UL94 V-0
- Tip
- Plug, Female Sockets
- Material Flammability Rating
- UL94 V-0
- Kurşunsuz Kodu
- yes
- Gerilim
- 300V
- Additional Feature
- PA, 94V-0
- HTS Kodu
- 8536.69.40.40
