Volume pricing
- 1+ pcs$2.29
- 10+ pcs$2.16
- 100+ pcs$2.04
- 500+ pcs$1.92
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Min
- 12 AWG
- Safety Approval
- UL
- Özellikler
- Mating Flange, Retention Latches (Wire Side)
- Wire Cross Section
- 2.5 mm2
- Uzunluk
- 12.6mm
- Currentiec
- 12A
- Number Of Ways
- 7
- Yükseklik
- 26mm
- Flammability Rating
- UL94 V-0
- Material Flammability Rating
- UL94 V-0
- Tip
- Plug, Female Sockets
- HTS Kodu
- 8536.69.40.40
- Montaj
- Free Hanging
- Insulation Height
- 1.024 26.01mm
- Kurşunsuz Kodu
- yes
- Gerilim
- 300V
- Additional Feature
- PA, 94V-0
- Number Of Levels
- 1
- Screw Size
- M3
- Montaj Tipi
- Free Hanging (In-Line)
- Akım Değeri
- 12A
- ECCN Kodu
- EAR99
- Akım
- 15A
- Terminal Stili
- Screw - Rising Cage Clamp
- Housing Material
- Polyamide (PA), Nylon
- Pozisyon Sayısı
- 7
- Yayın Yılı
- 2011
- Number Of Decks
- 1
- Pitch
- 0.200 5.08mm
- RoHS Durumu
- RoHS Compliant
- Contact Plating
- Tin
- Parça Durumu
- Active
- Genişlik
- 45.72mm
- Sıra Sayısı
- 1
- Fabrika Tedarik Süresi
- 4 Weeks
- Terminal
- Screw
- Voltageiec
- 630V
- Renk
- Green
- Nominal Gerilim
- 250V
- Wire Gauge Max
- 30 AWG
