Volume pricing
- 1+ pcs$10.04
- 10+ pcs$9.47
- 100+ pcs$8.93
- 500+ pcs$8.43
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Özellikler
- Mating and Mounting Flange
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Gerilim
- 300V
- Wire Strip Length
- 7mm
- Pitch
- 0.150 3.81mm
- Number Of Ways
- 12
- Uzunluk
- 56.11mm
- Safety Approval
- UL
- Akım Değeri
- 8A
- Weight
- 203.999993g
- HTS Kodu
- 8536.69.40.40
- Orientation
- Straight
- Max Current Rating
- 8A
- Voltageiec
- 320V
- Terminal Stili
- Screw - Rising Cage Clamp
- Wire Gauge Max
- 30 AWG
- Wire Gauge Or Range Awg
- 14-30 AWG
- Max Supply Voltage
- 160V
- RoHS Durumu
- RoHS Compliant
- Nominal Gerilim
- 160V
- Genişlik
- 12.5mm
- Flammability Rating
- UL94 V-0
- Gender
- Female
- Kurşunsuz Kodu
- yes
- Ambalaj
- Bulk
- Number Of Decks
- 1
- Renk
- Green
- Housing Material
- Polyamide (PA), Nylon
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Screw Size
- M2
- Contact Plating
- Tin
- Depth
- 12.5mm
- Number Of Contacts
- 12
- Material
- Polyamide
- Onay Kuruluşu
- CB, CSA, VDE, cULus
- Terminal
- Screw
- Connector Type
- Plug, Screw
- Seri
- COMBICON MCVU
- Montaj
- Cable, Panel
- REACH Uyumluluk Kodu
- unknown
